System Monitoring WDM system Transmitters and Fiber Fiber optical amplifier Fiberoptic lnstruments
Wide Wavelength Range Low Insertion Loss WDM system High Channel Isolation High stability and reliability
|
|
Parameters
|
Unit
|
Specifications
|
|
|
1
|
Transmission working wavelength
|
nm
|
1480 ~ 1500
|
|
|
2
|
Reflected working wavelength①
|
GHz
|
1260 ~ 1360
|
|
|
3
|
Reflected working wavelength②
|
nm
|
1540 ~ 1560
|
|
|
4
|
Channel Insertion Loss
|
dB
|
≤0.80 (Typical 0.60)
|
|
|
5
|
Reflection Channel Insertion Loss
|
dB
|
≤0.60 (Typical 0.35)
|
|
|
6
|
Insertion loss flatnessn
|
dB
|
<0.3
|
|
|
7
|
Insertiont Channel Isolation
|
dB
|
>30
|
|
|
8
|
Reflection Channel Isolation
|
dB
|
>15
|
|
|
9
|
Return Loss
|
dB
|
>50
|
|
|
10
|
Directivity
|
dB
|
>50
|
|
|
11
|
Polarization Dependent Loss
|
dB
|
<0.10
|
|
|
12
|
PMD
|
ps
|
<0.10
|
|
|
13
|
Power Handling
|
mW
|
500
|
|
|
14
|
Operation Temperature Range
|
℃
|
-40 to +80
|
|
|
15
|
Storage Temperature Range
|
℃
|
-40 to +80
|
|
|
16
|
Fiber Jacket & Fiber Length
|
cm
|
Customized
|
|
|
17
|
Package Dimensions-Type 1
|
mm
|
< 3.8 (Φ) * 30 (L)
|
|
|
|
Package Dimensions-Type 2
|
mm
|
< 4.2 (Φ) * 30 (L)
|
|
|
|
Package Dimensions-Type 3
|
mm
|
< 5.5 (Φ) * 58 (L)
|
|
|
18
|
Fiber Type
|
G.652D / G.657 A1 (or Customized)
|
|
|
|
19
|
Fiber Marking
|
Customized
|
|
|
We are a leading company in developing and manufacturing advanced fiber optic products,mainly make fiber optic indoor and outdoor cable, CPRI waterproof jumper, MPO/MTP jumper , standard fiber optic jumper and PLC Splitter.
With years of experiences in the fiber optic industry, our factory is fully equipped over 3500 square meters and more than 23 non dust production lines .About 200 well-trained staff and engineers are contributing to our proud products. We have 5 production lines for fiber optic cable, 2 high standard MPO/MTP jumper assembly lines, 8 production lines for standard jumper and 8 PLC Splitter production lines.
The most advanced imported polishing equipment and testing instruments enable our products have super quality, such as Senko polishing machine, interferometer, automatic cleaning machine and OTDR ,JGR and so on.
All of our optical products are RoHS compliant and also obtained ISO9001, ISO14001 certification. Our high quality products and outstanding service win the customer from all the world, Our fiber optic is looking forward to cooperate with you.
We always learn new technology by investing in production facilities, engineering process control systems, and talent development to maintain our status as a leading fiber optic connection solutions.
Within 1-2 working days
3-7 working days according various quantities
1. How many staff's we have?
Answer: About 200 well-trained staff and engineers.
2. What's our main products?
Answer: We dedicate to the developing, production, marketing of the Fiber Optic Cable,
Indoor/Outdoor Patch Cord, Splitter, Adapter, Attenuator, and so on.
3. What is the area of the factory?
Over 3500 square meters
More than 18 non dust productions lines in total
4 production lines for Fiber Optic Cable
2 high standard MPO/MTP Jumper assembly lines
8 production lines for standard Jumpe
4 PLC Pplitter production lines
4. What certificate we have?
Answer: ISO 9001: 2015, RoSH, CE, High and New Tech Enterprise Certficate.
