FHM2A01
|
FHM2B01
|
|
|
Power
Meter
|
Calibration wavelength(nm)
|
850/1300/1310/1490/1550/1625
|
|
|
|
|
Connector
|
Interchangeable FC/SC/ST for PC/APC
|
|
|
|
|
Data storage(items)
|
999
|
|
|
|
|
Ref.Value
|
Yes
|
|
|
|
|
Display units
|
dB/dBm/mW/uW
|
|
|
|
|
Display precision(dB)
|
0.01
|
|
|
|
|
Accuracy
|
±5%±1nW
|
|
|
|
|
Wavelength recognition
|
1310/1490/1550/(input power≥-40dBm)
|
|
|
|
|
Tone detection
|
270Hz/1KHz/2KHz(input power≥-40dBm )
|
|
|
|
|
Measuring range(dBm)
|
-70 to +10
|
-50 to +26
|
|
|
Laser
Source
|
Output wavelength(nm)
|
1310/1490/1550
|
|
|
|
|
Connector
|
Interchangeable FC/SC/ST for PC
|
|
|
|
|
Modulation frequencies
|
270/1K/2K Hz
|
|
|
|
|
Output power1
|
-5dBm±0.5dB
|
|
|
|
|
Stability long-term(8h)1
|
±0.1dB@1310/1550nm
|
|
|
|
|
Stability short-term(15min)1
|
±0.05dB@1310/1550nm
|
|
|
|
|
Wavelength recognizing code
|
Yes
|
|
|
|
General
Specification
|
Auto power off
|
√
|
|
|
|
|
Power supply
|
2pcs *NiHM 1.2V,2000mAh;AC/DC Adaptor
|
|
|
|
|
PC interface
|
USB
|
|
|
|
|
Battery life
|
>100Hours(laser off)
|
|
|
|
|
Storage temperature
|
-20°C~+70°C
|
|
|
|
|
Operating temperature
|
-10°C~+50°C
|
|
|
|
|
Relative humidity
|
<90%(Non-condensing)
|
|
|
|
|
Dimension(mm)
|
168L×76W×43H
|
|
|
|
|
Weight(Gram)
|
310
|
|
|
