• 2.5mm universal connector, • Operates either in CW or Pulsed mode with constant output power • Long battery life (up to 60 hours) • drop-resistant and dust-proof design of laser head • Laser case ground design prevents ESD damage • Portable and rugged • Easy to use • Meets CE standards including EMC, EMI, ROHS
• Maintenance in telecom , CATV • Test Lab of optical fibers • Fiber routing and continuity checking in optical networks. • Other fiber optic measurements
|
Model
|
SX-VFL650
|
|
Central wavelength
|
650nm±10nm
|
|
Emitter type
|
FP-LD
|
|
Output power
|
Optional choice for 5mw, 10mw,20mw,30mw,40mw
|
|
Optical connector
|
2.5mm universal connector, for 1.25mm connectors, FC (Male)-LC. (Female) convertor can be provided on request
|
|
Operating model
|
Both CW and Pulse available
|
|
Pulse frequency
|
3Hz to 9Hz
|
|
Power supply
|
2AA alkaline batteries
|
|
Operating temperature
|
-20°C to 60°C
|
|
Storage temperature
|
-40°C to 85°C
|
|
Dimension
|
-FL-002 Φ23 X 190
|
|
Weight
|
184g (without battery)
|
